DIP Varistor
large-size 20mm, the product flow capability is 10KA and a surge capability is 20KV. More voltage:18V-1800V
item no.:
VDR-20D241Klead time:
2-4 Weekproduct orgin:
Chinashipping port:
Chinapayment:
CODcolor:
blueThe varistors used in the platooninsert are mainly the large-size 20MM, the product flow capability is 10KA and a surge capability is 20KV. It is used in over-voltage protection to prevent excessive voltage from causing burnout of the product which is a safety protection product and has passed UL certification and Canada CSA certification, VDE United States certification, the company has focused on over-voltage production for more than 20 years, the company has always been product quality as the center and dedicated to reliability products, if you have problems about technical products , the company can promptly resolve for you.
previous :
Automotive electronic DC circuit 12V protection varistor 07D270Knext :
Zinc Oxide varistors 14D470V for Power supplyYou are interesting in this products
Product size:05D,07D,10D,14D,20D,25D voltage:18V-1800V surge:100A-20KA
size:7mm,More voltage:18-820V,Through-flow: 1200A-1750A, applied in car cigarette lighter, charger, and stereo, windows, mainly used as over-voltage protection
Product size:5MM,voltage:18V-510V,Through-flow: 500A-800A，Surge passing capacity: 1KV-1.5KV has passed UL certification and Canada CSA certification, VDE United States certification
size:14mm,voltage:470V,Pin distance:10mm,Throughflow is 6.5KA, voltage is 470V (220/230V) The products passed UL, VDE, CSA, CQC, ISO,
Size: KG3D05B350=05.0x7.2mm, Voltage: 350V, Throughflow: 5000A, More voltage: 90V, 150V, 230V, 350V, 420V, 470V, 600V
Size:0805, Temperature coefficient: C0G: 0±30ppm/°C; Capacity drift: no more than ±0.2% or ±0.05pF, whichever is greater;
