Chip Varistor 0402
Suitable for ESD protection Low cap design (0.2pf) for fast data transmission Fast response time (<0.5ns)
item no.:
MVR0402-240E2R5lead time:
2-4 Weekproduct orgin:
Taiwanshipping port:
Chinapayment:
CODcolor:
blackSurge Varistor,LEd Lighting Chip Varistor,Chip Varistor,SMD Varistor,ESD Varistor
Series size from 0402 to 2220,(3220)08CH
Working Voltage from 2V to 560V dc
Low cap design (0.2pf) for fast data transmission
Fast response time (<0.5ns)
Low leakage current
High surge current ability
Suitable for ESD protection
Bidirectional clamping, high energy
Wide Operating temperature range from-55℃-125℃
Good Temperature Coefficient
Low cap design (0.05pf-56pf) for fast data transmission，Fast response time (<0.5ns)，Low leakage current，Suitable for ESD protection，Wide Operating temperature range from -55℃-125℃，Series size from 0402，0603，0805，1206
You are interesting in this products
voltage :8V,12V,18V,24V,27V,30V,33V,39V,42V,47v,56V,68V,76V,82V,100v,120V,170V,240V,270v,390V,430V,470V Surge passing capacity: 500V-1KV
Resistance: 0Ω-1000Ω Size: 0402, 0603, 0805, 1206
Size:0603(1.6*0.8),precision factors of 1%-5%,resistance have a resistance value of 1K-1M, has a small volume and strong stability, applicable to be mounted to various surfaces of high density
Size: 2R09=8.3mmx6.0mm，Throughflow:10KA-12KA，Accuracy: 20%
High Capacity Chip Capacitor:1PF-100UF,Voltage:6.3V-100V, size: 0603, 0805, 1206, 1210, 1808, 1812, 2220, 2225, 2211, 3035
Product Voltage： 50V, 100V, 150V, 200V, 300V, 400V, 600, 800, 1000 Product Current: 1A, 2A, 3A, 4A, 5A, 6A, Sealed Packaging: SMAF, SMAJ, SMBJ, SMCJ
